Product Overview
The VPixx Projector Stand is an adjustable-height stand designed to support the PROPixx projector or SHIELDPixx shielding enclosure in MRI and MEG environments. The stand is constructed entirely from MRI-safe, non-ferromagnetic materials. Features include:
-
Adjustable height range: 30" to 43"
-
Constructed entirely from MRI-safe, non-ferromagnetic materials
-
Compatible with PROPixx projector and SHIELDPixx enclosure
Product Details
The stand consists of two vertical legs with height-adjustment collars and a top shelf that supports the PROPixx projector or SHIELDPixx enclosure.
Technical specifications:
-
Adjustable height range: 30" to 43"
-
All materials are non-ferromagnetic and MRI-safe
Assembly and Installation
What's included
|
Qty |
Item |
MR safe? |
|---|---|---|
|
1x |
Projector stand (adjustable, MSR-safe materials) |
Yes |
|
1x |
Allen key |
Yes |
General recommendations
Ensure that you observe the following before beginning assembly:
-
Assemble this product outside the MSR. Never unpack and/or assemble your products in the room with the magnet.
-
Two people are recommended when placing the SHIELDPixx on the assembled stand.
Assembling the stand
To adjust the top shelf height, use the Allen key to loosen the two screws on each leg collar. Slide the shelf to the desired height, and tighten the screws to lock the stand in place.
Product Usage
The projector stand supports the PROPixx projector or SHIELDPixx enclosure inside the magnetically shielded room. Once the stand is assembled and the projector or enclosure is in place, adjust the height to align the projection beam with the mirror and screen.
For complete installation instructions including projector placement, mirror alignment and image focusing, see the following product manuals:
-
PROPixx Projector
-
SHIELDPixx Shielding Enclosure
-
Projection Mirror
Product Specifications
General specifications
-
Stand height range: 30" to 43" (adjustable)
-
MR safety rating: MR Safe (non-ferromagnetic materials throughout)
-
Compatible with: PROPixx projector, SHIELDPixx shielding enclosure
Cleaning and Maintenance
The projector stand has a metal frame constructed from non-ferromagnetic materials. It can be cleaned with regular cleaning products or disinfectants. Spray the product into a soft cloth and wipe down the stand — do not directly spray the product on the stand.
Troubleshooting your Device
|
Issue |
Solution |
|---|---|
|
Stand is wobbly or unstable |
Ensure all screws are fully tightened, including the height-adjustment collar screws. |
|
Height adjustment is stiff |
Loosen both screws on each leg collar before attempting to slide. Do not force the adjustment with only one screw loosened. |
Related Links
Compliance, Safety and Warranty Information
Click on the sections below to expand the relevant information.
Safety and Warnings
The following table shows MR safety warning indicators and their names and meanings. Please pay special attention to the symbols on your equipment, and obey all guidelines to protect staff and equipment from injury.
|
Symbol |
Name |
Description |
|
MR safe |
Components marked with the green MR safe indicator present no danger to staff and equipment operating in the MR room. |
|
Conditionally MR safe |
The yellow Conditionally MR safe indicator denotes components that are only MR safe in a limited fashion. Product-specific safety requirements apply. For additional details, consult the product manual's safety section. |
|
MR unsafe |
The red MR unsafe indicator denotes components prohibited from entering the MR room. |
